Corrosion Inhibitor Multifunctional Closed Chilled Systems

Description

RXSOL-40-4011-210 is a superior multifunctional, nitrite-based chemical treatment used for the control of corrosion in closed cooling systems and chilled water systems. RXSOL-40-4011-210 is a liquid product containing a combination of ferrous and non-ferrous corrosion inhibitors, a non-carbonate buffer, scale inhibitors, dispersants and a leak detection dye.

Note: The stable oxide film that is formed by RXSOL-40-4011-210 prevents corrosion caused by electrolytic action between dis -similar metals used in the system.RXSOL-40-4011 has been field tested and found to have no detrimental effects on non metallic substances such as seals, glands,packing,hoses, gaskets etc., normally used in these’systems.

Application for DG-Sets

Internal combustionengines closed circuit cooling system compressor cooling system.RXSOL-40-4011-210 incorporates superior corrosion inhibitors to prevent corrosion works by free of scale deposits.

Advantages

Prolong the life of equipment by keeping scale and corrosion free. Since RXSOL-40-4011-210 is alkaline and so will suppress acid corrosion, which would otherwise result in corrosion damage such as pitting. However, the alkalinity control  is such that even if the product is accidentally overdosed, the pH of the water will remain within limits. The  metals which would be affected by extremes of alkalinity or acidity are protected

• Improves generating cooling efficiency by maintaining a clean heat transfer
• Reduced maintenance and down   time
• Compatible with Coolants / Antifreeze solution / Glycol .
• Friendly with   Metals (Like steel, Copper, Aluminum, all alloys) & Non-metal (Rubber, Hoses, Gasket etc.)

Note: In cases where systems are contaminated with oil and/or scale they should be cleaned before starting to apply RXSOL-40-4011-210.There are suitable RX BRAND products to carry out the cleaning. Degreasing should be carried out using RXSOL-10-1005-OB and descaling by using RXSOL-11-1008-DC

Method Of  Use

Note: Initial dosage for an untreated system is 9 litres of RXSOL-40-4011-210 /1000 litres of untreated distilled water.This will bring the treatment up to the minimum level of 1000 ppm nitrite.For best  result and  prolonged  engine life add  RXSOL-40-4011-210  every  500 -6500  km. or  250  to  300 hours  of  running  time  or  every  2 month   interval.

1. Properly   clean  the  system  with  water  and  alkaline  liquid ,  if  necessary.
2. The recommended dosage of RXSOL-40-4011-210 is 15.6-23.4 l/m3 of system capacity or 60.6-87 RXSOL-40-4011-210 of system capacity in all systems. Clean up the system if the system becomes contaminated with iron. Maintain 600-750 ppm nitrite as NO2. RXSOL-40-4011-210  is intended for industrial use only. It should not be fed to potable water systems
3. When the product is dosed as recommended  limit By buffering action of RXSOL-40-4011-210 ,pH should be maintained between 8.3 and 10 by the treatment.

Specification

Color: Clear

pH:Alkaline

Odour:None

Handling: RXSOL-40-4011-210 is an alkaline product &should be handled like other chemical Avoid contact with Eyes,Skin,in case of contact,wash with copious amounts of water  immediately

How Corrosion Inhibitors Improve Cooling Tower Efficiency

Cooling towers operate with large volumes of circulating water, often containing dissolved oxygen, salts, and other impurities that can accelerate corrosion in metal components. Corrosion inhibitors are essential for protecting system integrity and enhancing operational efficiency.

Benefits of Corrosion Inhibitors in Cooling Towers:

Protects Metal Surfaces
Forms a passive film on metal parts (like pipes, heat exchangers, and tower basins), preventing corrosion by blocking reactive sites.

Maintains Thermal Efficiency
Prevents buildup of corrosion by-products (like rust) that reduce heat transfer and clog piping.

Reduces Maintenance and Downtime
Minimizes system failures due to leaks, thinning walls, and component breakdowns caused by internal corrosion.

Extends Equipment Life
Keeps expensive assets like chillers, condensers, and pumps in good condition for longer operational lifespan.

Improves Water Circulation Efficiency
Prevents blockages and uneven flow caused by rust or scale fragments circulating in the system.

Enhances Treatment Program Performance
Works in synergy with scale inhibitors and biocides for a fully optimized water treatment system
